T600-4 Rockfort Fosgate Power 600 Watt 4-Channel Amplifier
582 CHF
Technical Specifications:
| Number of Channels | 4 |
| Total Power(Sum of Rated Power) | 600 Watts RMS |
| Rated Power(RMS Continuous Power) | 100 Watts x 4 @ 4-Ohm 150 Watts x 4 @ 2-Ohm 300 Watts x 2 @ 4-Ohm Bridged 2-Ohm x 2 Bridged Stable |
| Dynamic Power(PVC/PowerCube®) | Front Channels 139 Watts x 2 @ 4-Ohms 0° Res 236 Watts x 2 @ 2-Ohms 0° Res Rear Channels 140 Watts x 2 @ 4-Ohms 0° Res 236 Watts x 2 @ 2-Ohms 0° Res |
| Bridgeable | Yes |
| Frequency Response | 20Hz to 20kHz +/- 1dB |
| Input Sensitivity | 150 mV to 4 V |
| Circuit Topology Class | Class A/B |
| Efficiency (average) | 70% @ 4-Ohm 64% @ 2-Ohm |
| Total Harmonic Distortion (THD+Noise) | 4-Ohm: <1.0% 2-Ohm: <1.0% |
| Signal Input | Front Low level: 1 RCA pair Rear Low level: 1 RCA pair Input Switch: 2CH / 4CH |
| Signal Output | Low Level: 1 RCA pair |
| Tone Controls | Front Channels – Punch EQ Treble: 0dB to +12dB @ 12kHz Bass: 0dB to +18dB @ 45Hz Rear Channels – Punch EQ Treble: 0dB to +12dB @ 12kHz Bass: 0dB to +18dB @ 45Hz |
| Crossover Controls | Front High-Pass (HP): 50-500Hz 24dB/octave Butterworth Front Low-Pass (LP): 50-500Hz 24dB/octave Butterworth Rear High-Pass (HP): 50-500Hz 24dB/octave Butterworth Rear Low-Pass (LP): 50-500Hz 24dB/octave Butterworth |
| Remote Controls | Optional Remote Punch EQ |
| Visual Indicators | Power Thermal Protect |
| Power Wire Gauge | 4 AWG |
| Power Input Connector | Block |
| Speaker Wire Gauge | 8 AWG to 18 AWG |
| Speaker Output Connector | Screw terminal barrier strip |
| Cooling | Convection |
| Operating Voltage | 9 – 16 VDC |
| Recommended Fuse(not included) | 80 A |
| Average Current Draw (13.8V Music) | 40 A |
| Max. Current Draw (13.8V Sinewave) | 80 A |
| Suggested Alternator | 75 A |
| Dimensions (H x W x D) | 2.14 x 8.14 x 14.91 (in) 5.42 x 20.68 x 37.86 (cm) |
| Shipping Weight | 12.00 Lbs. (5.44 Kg.) |
- Description
- Reviews (0)
Description
The Power T600-4 is a 4-channel amplifier capable of producing 150 Watts into each of its four channels at 2-Ohms. The T600-4 can run a 4-way full-range system or use component speakers on the front with subwoofers on the rear.
The T600-4 amplifier offers the perfect balance of power output and compact design required for high performance audio systems. The 4-channel configuration allows fine tuning adjustments between front stage component systems and rear surround speakers. The built-in crossover also allows the rear channels to be configured for running one or two subwoofers.
